In order to take full advantage of the enormous design freedom offered by Additive Manufacturing (AM) technologies, the use of Topology Optimization (TO) methods becomes essential. Although TO is well-established in many disciplines, the problems in vehicle crashworthiness pose severe difficulties for standard, gradient-based approaches, due to high noisiness, multi-modality, and discontinuous nature of the nonlinear simulation responses considered typically as objectives and constraints. In this article, we propose to use Evolutionary Algorithms (EAs) together with a suitable low-dimensional representation in an extended version of the Evolutionary Level Set Method (EA-LSM), able to address complex 3D crash TO problems. The method is used to optimize a 3D-printed metal joint in a hybrid S-rail structure under axial crash loading, inspired by novel frame design concepts in industry. The obtained results show that the method is capable of handling optimization problems with multiple constraints, including challenging acceleration responses, and yields significantly better solutions than the state-of-the-art methods. Finally, the robustness of the obtained designs is studied, demonstrating the ability of EA-LSM to find designs of low sensitivity w.r.t. small variations of the loading conditions, which is crucial from the perspective of industrial applications of the proposed method.

Abstract Topology optimization (TO) is used in the initial design phase to optimize certain objective functions under given boundary conditions by finding suitable material distributions in a specified design domain. Currently available methods in the industry work very efficiently to get topologically optimized design concepts under static and dynamic load cases. However, conventional methods do not address the designer’s preferences about the final material layout in the optimized design. In practice, the final design might be required to have a certain degree of local or global structural similarity with an already present good reference design because of economic, manufacturing, and assembly limitations or the desire to re-use parts in different systems. In this article, a heuristic energy scaling method (ESM) for similarity-driven TO under static as well as dynamic loading conditions is presented and thoroughly evaluated. A 2D cantilever beam under static point load is used to show that the proposed method can be coupled with gradient-based and also heuristic, nongradient methods to get designs of varying similarity with respect to a reference design. Further testing of the proposed method for similarity-driven TO on a 2D crash test case and a large-scale 3D hood model of a car body indicates the effectiveness of the method for a wide range of problems in the industry. Finally, the application of similarity-driven TO is further extended to show that ESM also has the potential for sensitivity analysis of performance with respect to the extension of design domain.
